ESD PEEK
JUTAIPEEK?ESD6-B is a type of Polymeric Profiles made from electrostatic-dissipative Polyetherether Ketone
(PEEK). It is a kind of polymeric materials with outstanding mechanical properties, heat-resistance, resistance to
chemicals, wear resistance and antistatic property.
This type of products can be applied as auxiliary material in semiconductor products production, components
and parts of semiconductor products, and industrial explosion-proof. It mainly is used in handling high-sensitivity
components and can remarkably minimize the failure of the electronics components.
Product Features
JUTAIPEEK?ESD6-B type electrostatic-dissipative
PEEK profiles:
● High stiffness and mechanical strength.
● Good sliding frictional property.
● High dimensional stability.
● Outstanding antistatic property and the surface resistivity
=106 -109 Ω/sq.
● High uniformity of surface resistivity distribution.
● Black color, and uniform color.
● No small molecule substance releasing and no solid powder outgassing, and very clean.
Application Fields
JUTAIPEEK?ESD6-B type electrostatic-dissipative PEEK profiles can be
applied:
——?Mechanical Engineering Industry；
—— Material Handling Industry；
—— Electronic Industry；
—— Chemical Industry.
Instructions for Use
Machined by Lathes or Milling Machine.
Remove surface heat-treatment aged layers and the thickness of
removal layer is 0.5-2mm.
Product Storage Instructions
Placed away from light, avoiding humid, and away from oily substance.
Packed with polymeric film when not use.
Product Technical Data
The performance of JUTAIPEEK
?ESD6-B series products is as follows:
|
Performance
|
Test Method
|
Unit
|
Standard
|
|
Color
|
Eye
|
/
|
Black
|
|
Density
|
ISO?1183-1
|
g/cm3
|
1.37
|
|
Tensile Strength
|
ISO 527-2
|
MPa
|
≥105
|
|
Tensile Modulus
|
ISO 527-2
|
GPa
|
≥5.5
|
|
Elongation At Break
|
ISO 527-2
|
%
|
≥3
|
|
Charpy Impact Strength
|
ISO?179
|
KJ/m2
|
≥4.0
|
|
Flexural Strength
|
ISO?178
|
MPa
|
≥150
|
|
Flexural Modulus
|
ISO?178
|
GPa
|
≥4.1
|
|
Rockwell Hardness
|
ISO?2039-2
|
HRM
|
≥100
|
|
Melt Temperature
|
ISO?11357-3
|
℃
|
≥334
|
|
Thermal Conductivity
|
ISO?8302
|
W/ (m?K)
|
≤0.5
|
|
Coefficient of Linear Thermal Expansion 20-100℃
|
ISO 11359-2
|
10-6/K
|
≤50
|
|
Long Service Temperature
|
UL 746B
|
℃
|
240
|
|
Heat Deflection Temperature
|
ISO?75-2
|
℃
|
≥170
|
|
Water Absorption（ 24h）
|
ISO?62
|
%
|
≤0.11
|
|
Flame Retardancy
|
UL?94
|
/
|
V-0
|
|
Volume Resistivity
|
IEC61340-2-3
|
Ω?cm
|
107-1010
|
|
Surface Resistivity
|
IEC61340-2-3
|
Ω/sq
|
106-109
|
Notes: Antistatic property is characterized by surface resistivity and the test methods are according to
IEC61312-3-2, ANSI/S.T.M11.11, and IEC61340-2-3. The preferred method is from IEC61340-2-3 and the testing
electrode is Concentric Ring Electrode.
